Fujitsu PRIMERGY RX300 S5 server 0 GB Rack (2U) Intel® Xeon® 5000 Sequence E5504 2 GHz 2 GB DDR3-SDRAM 800 W

Fujitsu PRIMERGY RX300 S5 server 0 GB Rack (2U) Intel® Xeon® 5000 Sequence E5504 2 GHz 2 GB DDR3-SDRAM 800 W

The Fujitsu PRIMERGY RX300 S5 server is equipped with an Intel® Xeon® 5000 Sequence E5520 processor running at 2.26 GHz frequency. It features four cores and eight threads, supporting Smart Cache for improved performance. With a total memory capacity of six gigabytes in three dual-channel configurations, this server supports DDR3-SDRAM up to speeds of 1066 MHz.

Despite having no physical storage space indicated on its specifications, it can accommodate up to 144 gigabytes of internal memory through multiple memory slots. The power supply unit provides 800 watts of energy, including redundant power support for enhanced reliability. This rack-mounted server operates within a temperature range of -40°C to +72°C, making it suitable for various environments.

Its compact design allows efficient use of space while maintaining high processing capabilities. Overall, the Fujitsu PRIMERGY RX300 S5 offers robust computing solutions tailored for demanding workloads.

Feature summary

  • Model: Fujitsu PRIMERGY RX300 S5 server 0 GB Rack (2U) Intel® Xeon® 5000 Sequence E5520 2.26 GHz 6 GB DDR3-SDRAM 800 W
  • Processor: E5520
  • CPU frequency: 2.26 GHz
  • sku: VFY:R3005SP020FR
  • Processor family: Intel® Xeon® 5000 Sequence
  • Processor manufacturer: Intel
  • Processor boost frequency: 2.53 GHz
  • Processor cores: 4

Additional information

Processor family

Intel® Xeon® 5000 Sequence

Processor manufacturer

Intel

Processor model

E5520

Processor frequency

2.26 GHz

Processor boost frequency

2.53 GHz

Processor cores

4

Processor cache

8 MB

Motherboard chipset

Intel® 5520

Memory channels supported by processor

Triple

Number of processors installed

1

Thermal Design Power (TDP)

80 W

Processor cache type

Smart Cache

System bus rate

5.86 GT/s

Maximum number of SMP processors

2

Processor socket

Socket B (LGA 1366)

Processor lithography

45 nm

Processor threads

8

Processor operating modes

64-bit

Stepping

D0

FSB Parity

No

Bus type

QPI

Processor codename

Nehalem EP

Tcase

72 °C

Maximum internal memory supported by processor

144 GB

Memory types supported by processor

DDR3-SDRAM

Memory clock speeds supported by processor

800,1066 MHz

Memory bandwidth supported by processor (max)

25.6 GB/s

ECC supported by processor

Yes

Execute Disable Bit

Yes

Idle States

Yes

Thermal Monitoring Technologies

No

Processor package size

42.5 x 45 mm

Processor code

SLBFD

Physical Address Extension (PAE)

40 bit

Embedded options available

No

Number of Processing Die Transistors

731 M

CPU multiplier (bus/core ratio)

17

Processing Die size

263 mm²

Processor system type

DP

Processor series

Intel Xeon 5500 Series

Conflict-Free processor

No

Internal memory

6 GB

Internal memory type

DDR3-SDRAM

Maximum internal memory

144 GB

Memory slots

18

ECC

Yes

Memory clock speed

1066 MHz

Memory layout (slots x size)

3 x 2 GB

Total storage capacity

0 GB
