APC Smart-UPS SC 620VA 230V

APC Smart-UPS SC 620VA 230V

The APC Smart-UPS is an uninterruptible power supply designed for Line-Interactive topology with an output capacity of 0.42 kVA and an output power rating of 260 W. It features four AC outlets compatible with C13 coupler types and includes a sealed lead acid (VRLA) battery technology capable of providing up to 84 VAh of backup energy.

This UPS model supports various compliance certifications including RoHS, REACH, PEPCO, and EOLI. Its typical backup time at full load is 5.5 minutes, while it can provide extended periods when operating under half-load conditions. Equipped with LED indicators for battery replacement status and equipped with surge protection against digital subscriber line (DSL), fax, modem, network devices among others, this unit also offers automatic restart functionality in case of power interruptions.

With dimensions ranging from 119mm x 368mm x 168mm and weighing approximately 9.09kg, the APC Smart-UPS comes fully packaged and includes essential accessories such as cables for RS-232 communication interface and software CDs for user manuals and additional utilities. Additionally, it boasts high efficiency levels exceeding 96%, low noise operation at 45dB during normal use, and hot-swap capabilities ensuring easy maintenance without downtime.

Notable features

  • Model: APC Smart-UPS uninterruptible power supply (UPS) Line-Interactive 0.42 kVA 260 W 4 AC outlet(s)
  • Colour: Grey
  • Weight: 9.09 kg
  • Width: 119 mm
  • Depth: 368 mm
  • Height: 168 mm
  • Frequency: 50/60 Hz
  • Noise level: 45 dB

Additional information

UPS topology

Line-Interactive

Output power capacity

0.42 kVA

Output power

260 W

Input frequency

50/60 Hz

Surge energy rating

320 J

Hold time (max)

2 ms

Efficiency

96.5%

Emergency Power Off (EPO)

No

Noise level

45 dB

Surge protection

Yes

Surge protection features

Digital Subscriber Line (DSL), Fax, Modem, Network

Audible alarm(s)

Yes

Audible alarm modes

Low battery alarm, Overload alarm

Auto-restart

Yes

AC outlet types

C13 coupler

Power plug

C14 coupler

AC outlets quantity

4 AC outlet(s)

Number of output IEC jumpers

2

Serial interface

Yes

Serial interface type

RS-232

Serial ports quantity

1

Battery technology

Sealed Lead Acid (VRLA)

Battery capacity

84 VAh

Typical backup time at full load

5.5 min

Typical backup time at half load

13.6 min

Battery life (max)

5 year(s)

Battery recharge time

3 h

Hot-swap battery

Yes

Automatic battery test

Yes

Form factor

Tower

Product colour

Grey

LED indicators

Battery replacement

Operating temperature (T-T)

0 – 40 °C

Storage temperature (T-T)

-15 – 45 °C

Operating relative humidity (H-H)

0 – 95%

Storage relative humidity (H-H)

0 – 95%

Operating altitude

0 – 3000 m

Non-operating altitude

0 – 15000 m

Compliance certificates

RoHS

Certification

REACH, PEP, EOLI

Cables included

RS-232

Manual

Yes

Width

119 mm

Depth

368 mm

Height

168 mm

Weight

9.09 kg

Software CD

Yes

Package width

262 mm

Package depth

508 mm

Package height

318 mm
