HP Z400 + ATI FirePro V3700 Intel® Xeon® 3000 Sequence W3540 6 GB DDR3-SDRAM Minitower Workstation

HP Z400 + ATI FirePro V3700 Intel® Xeon® 3000 Sequence W3540 6 GB DDR3-SDRAM Minitower Workstation

Next

HP Z400 + NVIDIA Quadro FX 1800 Intel® Xeon® 3000 Sequence W3540 6 GB DDR3-SDRAM Minitower Workstation

HP Z400 + NVIDIA Quadro FX 1800 Intel® Xeon® 3000 Sequence W3540 6 GB DDR3-SDRAM Minitower Workstation

HP Z400 + NVIDIA Quadro FX 380 Intel® Xeon® 3000 Sequence W3540 6 GB DDR3-SDRAM Minitower Workstation

HP Z400 + NVIDIA Quadro FX 380, 2.93 GHz, Intel® Xeon® 3000 Sequence, W3540, 6 GB, DDR3-SDRAM, DVD Super Multi

Documentation:

SKU: KK548ET+NB769ET Category: Brand:

HP Z400 + NVIDIA Quadro FX 380 workstation is equipped with an Intel® Xeon® 3000 Sequence W3540 CPU running at 2.93 GHz frequency. It features four cores and eight threads, supporting up to 24GB of DDR3-SDRAM RAM operating at 1333MHz. The system supports ECC memory for enhanced reliability.

The workstation includes various connectivity options such as multiple USB 2.0 ports, two PS/2 ports, one RJ-45 Ethernet port, microphone input, headphone output, and card readers. An optical drive and hard drives are also present, providing versatile storage solutions. With a power supply rating of 475W and weighing approximately 13.5kg, this workstation offers robust performance suitable for demanding work environments like high-end graphic design, video editing, and scientific computing tasks.

Its compact minitower chassis makes it ideal for small office settings or mobile professionals who require reliable hardware without occupying much space. Overall, the HP Z400 + NVIDIA QuadroFX 380 provides comprehensive capabilities tailored towards professional users seeking powerful computational processing and multimedia handling abilities.

Main specifications

  • Model: HP Z400 + NVIDIA Quadro FX 380 Intel® Xeon® 3000 Sequence W3540 6 GB DDR3-SDRAM Minitower Workstation
  • Processor: W3540
  • CPU frequency: 2.93 GHz
  • sku: KK548ET+NB769ET
  • Processor family: Intel® Xeon® 3000 Sequence
  • Processor manufacturer: Intel
  • Processor cores: 4
  • Processor threads: 8

Additional information

Processor family

Intel® Xeon® 3000 Sequence

Processor manufacturer

Intel

Processor model

W3540

Processor frequency

2.93 GHz

Processor cores

4

Processor threads

8

Processor boost frequency

3.2 GHz

Processor socket

Socket B (LGA 1366)

Processor cache

8 MB

Processor cache type

Smart Cache

System bus rate

4.8 GT/s

Bus type

QPI

FSB Parity

No

Processor lithography

45 nm

Processor operating modes

64-bit

Processor series

Intel Xeon 3500 Series

Processor codename

Bloomfield

Thermal Design Power (TDP)

130 W

Processor system type

Up

Tcase

67.9 °C

Number of processors installed

1

Number of Processing Die Transistors

731 M

Processing Die size

263 mm²

Stepping

D0

CPU multiplier (bus/core ratio)

22

Processor core voltage (AC)

0.800 – 1.225 V

Maximum internal memory supported by processor

24 GB

Memory types supported by processor

DDR3 800/1066

Memory bandwidth supported by processor (max)

25.6 GB/s

ECC supported by processor

Yes

Internal memory

6 GB

Maximum internal memory

16 GB

Internal memory type

DDR3-SDRAM

Memory clock speed

1333 MHz

ECC

Yes

Memory channels

Triple-channel

Optical drive type

DVD Super Multi

Number of HDDs installed

1

HDD capacity

1 TB

HDD interface

SATA

HDD speed

7200 RPM

Card reader integrated

Yes

USB 2.0 ports quantity

8

PS/2 ports quantity

2

Ethernet LAN (RJ-45) ports

1

Microphone in

Yes

Headphone outputs

1

Chassis type

Minitower

Country of origin

China
