HP xw6600 Workstation Intel® Xeon® 5000 Sequence E5405 2 GB DDR2-SDRAM Minitower

HP xw6600 Workstation Intel® Xeon® 5000 Sequence E5405 2 GB DDR2-SDRAM Minitower

HP xw6600 workstation is equipped with an Intel Xeon E5420 quad-core CPU running at 2.5 GHz. It features 2GB of DDR2 SDRAM operating at 667MHz, providing adequate memory for basic tasks. The machine supports up to 32GB RAM but currently has 2GB installed.

A 250GB hard drive operates on a SATA interface at 7200 RPM. This unit comes with seven USB 2.0 ports, two PS/2 ports, one RJ-45 Ethernet port, and includes microphone input and headphone output capabilities. The HP xw6600 runs on a mini-tower chassis designed specifically for compact workstations.

With a weight of approximately 18.1 kg, it offers reliable performance suitable for professional environments where space constraints are common. Although the processor does support ECC memory, this model doesn’t have built-in ECC functionality enabled by default. Additionally, while it’s primarily intended as a workstation, there aren’t embedded options like graphics cards or additional expansion slots typically found in more versatile systems.

Essential specs

  • Model: HP xw6600 Intel® Xeon® Quad Core 5420 2.50GHz 2GB/250GB DVD+/-RW WVST Bus Workstation Intel® Xeon® 5000 Sequence E5420 DDR2-SDRAM Mini Tower
  • Product type: Workstation
  • Processor: E5420
  • CPU frequency: 2.5 GHz
  • sku: PW459ET
  • Processor family: Intel® Xeon® 5000 Sequence
  • Processor manufacturer: Intel
  • Processor cores: 4

Additional information

Processor family

Intel® Xeon® 5000 Sequence

Processor manufacturer

Intel

Processor model

E5420

Processor frequency

2.5 GHz

Processor cores

4

Processor threads

4

Processor socket

LGA 771 (Socket J)

Processor cache

12 MB

Processor cache type

L2

Processor front side bus

1333 MHz

Bus type

FSB

FSB Parity

Yes

Processor lithography

45 nm

Processor operating modes

64-bit

Processor series

Intel Xeon 5400 Series

Processor codename

Harpertown

Thermal Design Power (TDP)

80 W

Processor system type

DP

Tcase

67 °C

Number of processors installed

1

Number of Processing Die Transistors

820 M

Processing Die size

214 mm²

Stepping

C0

CPU multiplier (bus/core ratio)

7.5

ECC supported by processor

No

Internal memory

2 GB

Maximum internal memory

32 GB

Internal memory type

DDR2-SDRAM

Memory layout (slots x size)

2 x 1 GB

Memory clock speed

667 MHz

ECC

Yes

HDD capacity

250 GB

HDD interface

SATA

HDD speed

7200 RPM

USB 2.0 ports quantity

7

PS/2 ports quantity

2

Ethernet LAN (RJ-45) ports

1

Microphone in

Yes

Headphone outputs

1

Chassis type

Mini Tower

Country of origin

China

Product type

Workstation

Motherboard chipset

Intel® 5400

Audio system

High Definition Audio

Intel® Wireless Display (Intel® WiDi)

No

Intel 64

Yes

Enhanced Intel SpeedStep Technology

Yes

Embedded options available

No

Intel® InTru™ 3D Technology

No

Intel® Insider™

No
