| Page description languages |
HP-GL/2, HP-RTL, TIFF
|
| Printing colours |
Cyan, Light Cyan, Light magenta, Magenta, Matte black, Photo black, Yellow
|
| Print head |
8 (cyan, magenta, matte black, photo black, yellow, light cyan, light gray, light magenta)
|
| Media types supported |
Bond and coated paper (bond, bright white bond, coated, heavyweight coated, super heavyweight coated, colored), technical paper (natural tracing, translucent, vellum), film (clear, matte, polyester white matte), photographic paper (gloss, semi-gloss, satin, matte), proofing paper (high-gloss, semi-gloss, matte), backlit, self-adhesive (indoor paper, polypropylene, vinyl), banner and sign (display film, banner, polypropylene, scrim, Tyvek, outdoor paper, blue back billboard paper), fabric (flag fabric, polyester, silk satin), fine art printing material (satin canvas, matte canvas, canvas paper, aquarella, watercolor, smooth, textured, litho-realistic)
|
| Media thickness |
> 0.56
|
| Maximum roll length |
175 m
|
| Maximum roll diameter |
17 cm
|
| Print margin roll |
5 mm
|
| Maximum media width |
1067 mm
|
| Roll top margin |
5 mm
|
| Ethernet LAN |
Yes
|
| USB port |
No
|
| RJ-45 ports quantity |
1
|
| Memory slots |
2x DIMM
|
| Internal memory |
256 MB
|
| Internal storage capacity |
40 GB
|
| Storage media |
HDD
|
| Built-in processor |
Intel® Celeron®
|
| Processor frequency |
2000 MHz
|
| Certification |
EU WEEE and RoHS Directives, US EPA's Energy Star
|
| Power requirements |
Input voltage 100 to 127 VAC (+/- 10%), 4 amp; 220 to 240 VAC (+/- 10%), 2 amp; 50/60 Hz (+/- 3 Hz); voltage autorange
|
| Power consumption (off) |
0.4 W
|
| Operating temperature (T-T) |
59 – 95 °F
|
| Operating relative humidity (H-H) |
20 – 80%
|
| Storage temperature (T-T) |
-25 – 55 °C
|
| Storage relative humidity (H-H) |
20 – 80%
|
| Compatible operating systems |
Microsoft Windows 2000, XP Home, XP Professional, Server 2003; Windows Vista Ready
|
| Sustainability certificates |
ENERGY STAR
|
| Dimensions (WxDxH) |
1970 x 700 x 1350 mm
|
| Weight |
119 kg
|
| Size (imperial) |
196.8 cm (77.5")
|
| Package weight |
195 kg
|
| Package dimensions (WxDxH) |
2260 x 750 x 1216 mm
|
| Bundled software |
HP Designjet software for Windows and Macintosh
|
| Minimum system requirements for Macintosh |
Mac OS X v 10.2.8, 10.3, 10.4; G3; 128 MB RAM; 256 MB available hard disk space
|
| Line accuracy |
+/- 0.1% of the specified vector length or +/- H50.1 mm (whichever greater)
|
| Minimum system requirements |
Microsoft Windows 2000, 2003 Server: Pentium II 300 MHz, 128 MB RAM, 400 MB available hard disk space; Windows XP: Pentium III 733 MHz, 128 MB RAM, 400 MB available hard disk space
Microsoft Windows 2000, XP Home, XP Professional: Pentium IV, 3 GHz, 1 GB RAM, 2 GB available hard disk
Mac OS X v10.2.8, 10.3, 10.4: 1 GHz PowerPC G4, 256 MB, 512 MB available hard disk space
|
| Embedded web server |
Yes
|
| Electromagnetic compatibility |
Compliant with Class A requirements, including USA (FCC rules), Canada (DoC), EU (EMC Directive), Australia (ACA), New Zealand (MoC), China (CCC), Japan (VCCI), Korea (MIC), Taiwan (BSMI)
|
| Printer management |
HP Embedded Web Server, HP Web Jetadmin
|
| Safety |
USA and Canada (CSA certified), EU (LVD and EN60950-1 compliant), Russia (GOST), Singapore (PSB), China (CCC), Argentina (IRAM), Mexico (NYCE)
|
| All-In-One-multitasking |
No
|
| Functions |
Print
|
| Print quality, vertical alignment accuracy |
+/- 0.0508 mm
+/- 0.0002 in
|
| Products per pallet |
1 pc(s)
|
| Pallet gross weight |
215 kg
|
| Print head nozzles |
2112
|
| Print speed (colour image, best quality, glossy paper) |
8.1 m2/hr
87 ft2/hr
|
| Print speed (colour image, draft quality, coated paper) |
60.8 m2/hr
654 ft2/hr
|
