HP DesignJet Z3100 GP 24-in Photo Printer/Advanced Profiling Solution Bundle

HP DesignJet Z3100 GP 24-in Photo Printer/Advanced Profiling Solution Bundle

HP Designjet Z3100 24-in Photo Printer large format printer Ethernet LAN

HP Designjet Z3100 24-in Photo Printer, Blue, Gloss enhancer, Green, Light Cyan, Light grey, Light magenta, Magenta, Matte black, Photo…, 6 (magenta and yellow, light magenta and light cyan, photo black and light gray, matte black and…, Photographic paper (satin, gloss, semi-gloss, matte), proofing paper (high-gloss, semi-gloss,…, > 0.8, 300 ft 91.4 m, 13.6 cm

Documentation:

SKU: Q5669A Category: Brand:

. The HP Designjet Z3100 is a large format photo printer designed to meet professional printing needs. It supports various print colors including Blue, Gloss enhancer, Green, Light Cyan, Light grey, Light magenta, Magenta, Matte black, Photo black, Red, Yellow, among others.

The print head consists of multiple components such as red, yellow, light cyan, blue, green, matte black, gloss enhancer, and more. This printer can handle a wide range of media types like photographic paper in different finishes, proofing papers, fine art materials, self-adhesive vinyls, sign banners, bond coated papers, etc., up to thicknesses over 0.8 mm.

Its maximum roll length reaches 300 feet, providing ample space for long prints. Equipped with Gigabit Ethernet interface and USB Type-A port, it offers efficient connectivity options. With an internal memory capacity of 128 MB and storage of 40 GB on HDD, this printer ensures smooth operation even during extended use.

Main characteristics

  • Model: HP Designjet Z3100 24-in Photo Printer large format printer Ethernet LAN
  • Weight: 65 kg
  • Dimensions (W×D×H): 1262 x 661 x 1047 mm
  • Package weight: 102 kg
  • Typical power consumption: 200 W
  • CPU frequency: 600 MHz
  • sku: Q5669A
  • Printing colours: Blue, Gloss enhancer, Green, Light Cyan, Light grey, Light magenta, Magenta, Matte black, Photo black, Red, Yellow

Additional information

Printing colours

Blue, Gloss enhancer, Green, Light Cyan, Light grey, Light magenta, Magenta, Matte black, Photo black, Red, Yellow

Print head

6 (magenta and yellow, light magenta and light cyan, photo black and light gray, matte black and red, gloss enhancer and gray, blue and green)

Media types supported

Photographic paper (satin, gloss, semi-gloss, matte), proofing paper (high-gloss, semi-gloss, matte), fine art printing material (canvas, smooth, textured, watercolor), self-adhesive and vinyl (polypropylene, vinyl), sign and banner (display film, banner, scrim, polypropylene, Tyvek, outdoor paper), bond and coated (bond, coated, heavyweight coated, super heavyweight coated)

Media thickness

> 0.8

Maximum roll length

300 ft
91.4 m

Maximum roll diameter

13.6 cm

Print margin cut-sheet

5 x 17 x 5 x 5

Print margin roll

5 mm

Maximum media width

610 mm

Roll top margin

5 mm

Ethernet LAN

Yes

USB port

Yes

Ethernet interface type

Gigabit Ethernet

USB connector

USB Type-A

USB 2.0 ports quantity

1

RJ-45 ports quantity

1

Internal memory

128 MB

Internal storage capacity

40 GB

Storage media

HDD

Built-in processor

Mobile Intel Centrino

Processor frequency

600 MHz

Certification

SWOP, ISO, GRACOL, 3DAP

Power requirements

Input voltage (autoranging): 100 to 240 VAC (+/- 10%), 50/60 Hz (+/- 3 Hz), 2 amps max

Power consumption (typical)

200 W

Operating temperature (T-T)

59 – 95 °F

Operating relative humidity (H-H)

20 – 80%

Storage temperature (T-T)

-13 – 131 °C

Storage relative humidity (H-H)

0 – 95%

Browser supported

Internet Explorer 5.0 and higher, Netscape 6.0.1 and higher, Safari for Mac OS 10.3 and higher, Mozilla 1.5 and higher

Compatible operating systems

Windows 2000; Windows XP Home; Windows XP Professional; Windows XP Professional x64; Windows Server 2003; Mac OS 10.2 or higher; Novell NetWare 5.x, 6.x; Citrix MetaFrame; Terminal Services

Sustainability certificates

ENERGY STAR

Dimensions (WxDxH)

1262 x 661 x 1047 mm

Weight

65 kg

Product dimensions when open (LxWxD)

126.2 cm (49.7")

Size (imperial)

126.2 cm (49.7")

Package weight

102 kg

Package dimensions (WxDxH)

1470 x 780 x 740 mm

Bundled software

Printer drivers, HP Printer Utility including HP Color Center

Minimum system requirements for Macintosh

Mac OS X v 10.2, v 10.3, v 10.4 and later; PowerPC G3 or Intel Core Processor; 256 MB RAM; 1 GB available hardware disk

Line accuracy

+/- 0.2 %

Minimum system requirements

Microsoft Windows 2000/XP: Pentium IV, 1 GHz, 512 MB RAM, 2 GB available hard disk space
Windows 2000: Pentium III processor, 512 MB RAM, 2 GB available hard disk space, 733 MHz; Windows XP Professional: Pentium IV processor, 512 MB RAM, 2 GB available hard disk space, 1 GHz
Microsoft Windows 2000/XP: Pentium IV, 1 GHz, 1 GB RAM, 2 GB available hard disk space
Mac OS X v10.2, v10.3, v10.4 and later, PowerPC G4, G5, or Intel Core Processor, 1 GB Ram, 2 GB available hardware disk

Embedded web server

Yes

Electromagnetic compatibility

Compliance for Class B products: EU (EMC Directive), USA (FCC rules), Canada (DoC), Australia (ACA), New Zealand (MoC), China (CCC), Japan (VCCI), Korea (MIC) and Taiwan (BSMI)

Printer management

HP Web Jetadmin

Safety

IEC 60950-1 compliant, EU LVD and EN 60950-1 compliant, certified by CSA for Canada and US, Argentina IRAM, Singapore PSB, Russia GOST, China CCIB, Taiwan BSMI

Maximum media length (imperial)

66"

Print resolution (colour, normal quality)

1200 x 1200 DPI

Products per pallet

1 pc(s)

Print head nozzles

2112
