The D-Link DES-1024D/B is an unmanaged desktop switch designed for fast Ethernet connectivity. It supports up to 24 RJ-45 ports that operate at speeds of either 10 Mbps or 100 Mbps in full-duplex mode. This switch complies with IEEE standards such as 802.1D, 802.3, 802.3U, and 802.3x, ensuring compatibility across various networking environments.
The switch has a switching capacity of 4.8 Gbit/s and features a MAC address table capable of storing up to 8000 entries. Its design includes LED indicators for activity, link status, and power supply, making it easy to monitor its operation. Despite being an unmanaged device, it offers several advanced functionalities including Quality of Service support, auto MDI/MDI-X functionality, and packet forwarding rates optimized for both low (10 Mbps) and high-speed (100 Mbps) connections.
Additionally, it operates within specified environmental conditions from -10°C to +70°C storage temperature and 0°C to +40°C operating temperature ranges, providing reliable performance under diverse conditions. With dimensions suitable for compact setups, this switch provides efficient wired network solutions without requiring additional stacking capabilities.
Product highlights
- Model: D-Link 24-Port Fast Ethernet Unmanaged Desktop Switch
- Colour: Black
- Weight: 1.14 kg
- Dimensions (W×D×H): 280 x 180 x 44 mm
- Width: 280 mm
- Depth: 150 mm
- Height: 44 mm
- Power source: AC
