be quiet! Dark Power Pro 10 power supply unit 1200 W 20+4 pin ATX ATX Black

be quiet! Dark Power Pro 10, 1200 W, 100 – 240 V, 1300 W, 50 – 60 Hz, 14 – 7 A, +12V1,+12V2,+12V3,+12V4,+3.3V,+5V,+5Vsb,-12V

Documentation:

SKU: BN205 Category: Brand:

The be quiet! Dark Power Pro 10 is an efficient and versatile power supply designed for PCs. With a total power output of 1200 W and peak capacity up to 1300 W, it meets various performance requirements while maintaining reliability through its active cooling system featuring a 13.5 cm fan at 2800 RPM.

It supports multiple connectors including 20+4 pin ATX motherboard power connector, 9 molex peripheral power connectors, and numerous SATA and PCI Express power connections. This PSU adheres to strict environmental standards like RoHS and complies with international certifications such as CE, CB, TÜV, Semko, FCC, CRUUS, and cTUVus.

Its MTBF exceeds 300,000 hours ensuring long-term stability. Ideal for enthusiast users seeking both high-performance capabilities and eco-friendly design considerations. Specifications also indicate that it has a noise level of 36.8 dB making it suitable for quieter environments.

Product highlights

  • Model: be quiet! Dark Power Pro 10 power supply unit 1200 W 20+4 pin ATX ATX Black
  • Colour: Black
  • Width: 150 mm
  • Noise level: 36.8 dB
  • sku: BN205
  • Total power: 1200 W
  • AC input voltage: 100 – 240 V
  • Peak power: 1300 W

Additional information

Total power

1200 W

AC input voltage

100 – 240 V

Peak power

1300 W

AC input frequency

50 – 60 Hz

Input current

14 – 7 A

Maximum input current (@110V)

+12V1,+12V2,+12V3,+12V4,+3.3V,+5V,+5Vsb,-12V

Power factor

0.99

Power Factor Correction (PFC) type

Active

Combined power (+3.3V)

150 W

Combined power (+12V)

1188 W

Combined power (+5V)

150 W

Max output current (+3.3V)

25 A

Max output current (-12V)

0.5 A

Max output current (+12V1)

35 A

Max output current (+12V2)

35 A

Max output current (+12V3)

45 A

Max output current (+12V4)

45 A

Max output current (+5V)

25 A

Max output current (+5Vsb)

3 A

Hold time

22 ms

Efficiency

93%

Power protection features

Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage

Motherboard power connector

20+4 pin ATX

Peripheral (Molex) power connectors (4-pin)

9

Number of SATA power connectors

11

PCI Express power connectors (6-pin)

1

PCI Express power connectors (6+2 pin)

8

CPU P4 connector (4-pin)

1

CPU power connector (4+4 pin)

Yes

Floppy drive power connector

2

CPU power connectors (8-pin)

1

Cabling type

Semi-Modular

Purpose

PC

Power supply unit (PSU) form factor

ATX

80 PLUS certification

80 PLUS Gold

ATX version

2.31

EPS version

2.92

Noise level

36.8 dB

Bearing technology

FDB

Mean time between failures (MTBF)

300000 h

Product colour

Black

Cooling type

Active

Fan diameter

13.5 cm

Number of fans

1 fan(s)

Fan speed

2800

Operating temperature (T-T)

0 – 40 °C

Compliance certificates

RoHS

Certification

CE, CB, TÜV, Semko (S), FCC, cRUus, cTUVus

Width

150 mm
